SC 12X6000MM Hydraulic Guillotine Shear For Sale is heavy-duty industrial cutting equipment used to shear steel plates with a thickness of 12 mm and a length of 6000 mm. They are commonly used in industries such as steel structures, shipbuilding, bridges, automobiles, and pressure vessels. The following are the general technical parameters and function introductions of this type of equipment.
The 12X6000MM hydraulic plate shearing machine is a hydraulically driven guillotine shearing machine. Its upper knife frame is driven by two main oil cylinders to shear downward along a fixed arc, achieving stable and efficient linear shearing action. The overall structure of the equipment is rigid and has a large cutting force, which is suitable for batch shearing of medium and thick plates.
Item | Parameters |
Shear thickness | 12 mm (Q235 steel, tensile strength ≤ 450 MPa) |
Shear length | 6000 mm |
Shear angle | 0.5°–2.5° (adjustable) |
Number of strokes | 6–12 times/minute (depending on the cutting length) |
Back gauge range | 20–1000 mm (electric adjustment) |
Main motor power | 22–30 kW (depending on the configuration) |
Machine weight | About 35–50 tons (depending on the structural design) |
Workbench height | 800–1000 mm |
Control system | CNC system such as E21S |
Blade material | High-strength alloy steels such as 6CrW2Si, Cr12MoV |
- Overall welded steel plate structure, annealing treatment, eliminating internal stress, ensuring high strength and stability.
- The upper tool holder adopts oblique blade shearing method, with small shearing force and flat shearing surface.
- Integrated hydraulic control system reduces pipeline connections and improves reliability.
- Hydraulic overload protection, smooth operation.
- The shearing angle can be adjusted according to different plate thicknesses to reduce shearing deformation and improve shearing quality.
- Electric adjustment, digital display control, optional servo or ball screw system to improve accuracy.
- Blocking and retreating function to prevent sheet metal from getting stuck during shearing.
- Manual/electric adjustment of the upper and lower blade gaps to adapt to plates of different materials and thicknesses.
- Simple electrical control is standard, and CNC system (such as Delem, ESTUN) can be optionally equipped to achieve multi-segment programming control.
Equipped with photoelectric protection, emergency stop button, foot switch two-hand start and other safety measures.
- The whole machine adopts an all-steel welded structure and undergoes heat treatment or vibration aging treatment to effectively eliminate welding stress and ensure long-term use without deformation.
- The frame structure has high strength and good torsion resistance, which is suitable for continuous high-load operation.
- Adopting dual cylinder synchronous drive, the shearing process is smooth and the impact is small.
- Equipped with a hydraulic overload protection system to ensure the safety and reliability of the equipment.
- The upper knife holder moves downward with a fixed oblique line (gate structure), which can effectively reduce shear distortion and ensure that the shearing surface is neat and straight.
- The shearing angle can be adjusted according to the plate thickness to optimize the shearing force.
- The upper and lower blade gaps can be fine-tuned according to the material and thickness of the plate to improve the shearing quality and extend the tool life.
- The standard digital display control system (such as E21S) and the optional high-end CNC system (such as Delem DAC series) can realize automatic shearing length setting, batch control, blade gap reminder and other functions.
- It can be equipped with an automatic feeding system or robot connection to realize unmanned shearing operation.
- Electrically adjustable back gauge, up to 1000mm, with digital display or servo control.
- Supports back gauge retreat function to avoid material jamming after shearing.
Ordinary carbon steel plate (such as Q235, Q345)
stainless steel plate
Aluminum alloy, copper plate
High-strength steel and other metal sheets.
Steel structure manufacturing: such as H-beam, box beam processing, etc.
Shipbuilding and offshore engineering: suitable for shearing large-size ship steel plates
Bridges and construction machinery: large-scale plate cutting
Pressure vessels: shearing high-strength steel plates for subsequent rolling
Mechanical and electrical manufacturing and equipment manufacturing plants: medium and thick plate processing
If you have any needs for 12X6000MM hydraulic guillotine shear, welcome to inquire! And we also have many other models of shearing machines for sale.
